Automatic Pen Assembly Machine 396A1

The Automatic Pen Assembly Machine 396A1 is a high-speed, fully automatic assembly solution designed for the stationery industry. With a capacity of 120-140 pieces per minute, this machine efficiently assembles pens using a 4-up chain carry horizontal configuration, ensuring consistent quality and high throughput. It is ideal for manufacturers of ballpoint pens, custom advertising pens, and industrial marking pens, helping to reduce labor costs and improve production efficiency.

Key Selling Points

• High-Speed Production: Achieves 120-140 pieces per minute, significantly boosting daily output and meeting large-scale production demands.
• Precise Assembly: The 4-up chain carry horizontal structure ensures accurate alignment and consistent quality, reducing defective rates.
• Versatile Applications: Suitable for stationery pens, custom promotional pens, medical marking pens, and more, offering flexibility for various production needs.
• Durable Construction: Built with a carbon steel frame, aluminum alloy components, and stainless steel parts, ensuring long-term stability and easy maintenance.
• Automation and Reliability: Full automatic feeding and assembly minimize manual intervention, lowering labor costs and operational errors.

Technical Specifications

Models and Options

This is the standard model 396A1. Customization options are available to meet specific production requirements, such as adjusting assembly modules for different pen types.

Materials and Structure

• Frame: Carbon steel, aluminum alloy, stainless steel
• Key Parts: Alloy steel, engineering plastic, rubber
• Control Units: Pneumatic & electric components

Applications

This machine is designed for the stationery and office supplies manufacturing industry, as well as custom advertising and gift pen production. It is also suitable for medical, industrial, and cosmetic marking pen applications, providing reliable assembly for a wide range of pen products.

Customization

We offer customization to adapt the machine to your specific pen design, including tooling adjustments and integration with existing production lines. Contact us to discuss your requirements.

FAQ

1. What is the MOQ for this machine?

MOQ is 1 set.

2. What is the delivery method?

FOB Shanghai port.

3. What are the payment terms?

50% advance payment, 50% balance paid before shipment.

4. What is the typical lead time?

Lead time depends on customization and current order volume; please contact us for details.

5. Is on-site installation and training provided?

Yes, we provide customer on-site factory acceptance and offer installation and training services.

6. What maintenance is required?

Regular cleaning and lubrication of moving parts are recommended. Our support team can provide guidance.

7. Can the machine handle different pen sizes?

Yes, with adjustments or tooling changes, it can handle various pen designs.

8. Does the company have export experience?

Yes, we have exported to over 20 countries, including the US, Japan, India, and many others.

Inquiry Information

For more details or a quotation, please contact us:

• Contact: Tiffany Zhou
• Email: zhouyt@szpaifeite.com
• Tel/WhatsApp: +86 18550217527
• Address: Building 3, No.25 Tangxi Road, Huqiu District, Suzhou City, Jiangsu Province, China

Image Gallery

Automatic Pen Assembly Machine 396A1 - main image and parts view.
